Siemens Centre of Excellence
MIT Campus
High End Equipment
Pulsed Laser System
Splitlight compact 100
Company : M/s Innolas Laser, Germany
Active Medium : Nd: YAG
Wavelength : 1064nm
Max Energy : 100mJ
Pulse Width : 6ns
Beam Diameter : 5mm
Q-switched DPSS lasers
Splitlight compact 100
Company : M/s Optogama, Germany
Active Medium : Nd: YAG
Wavelength : 1064nm
Max Energy : 1mJ
Pulse Width : 6ns
Beam Diameter : 3mm @ 1m
Spectrometer
Kymera 193i
Andor- oxford instruments
Resolution : 1nm
Grating: interchangeable ( 800 G/ mm and 1200 G/mm)
Focal Length : 193mm
Delay Generator
Delay Generator
Delay Output Channels : 4 nos
Resolution : 5ps
Wavelength : 1064nm
Max delay : 2000 s
External Trigger : Rising edge or falling edge
Interface : Ethernet, GPIB ad RS 232
Photo Multiplier Tube
Multiplier Tube
PMT type : Multialkali
Spectral response : 185 -900 nm
Photocathode active area : 3.7 mm X 13.0 mm
Rise and fall time : 1.4 ns
Settling time : 10 s
Server
Lenovo
Model : SR650
Processor : 16C, 2.1 GHz
RAM :16 GB HDD RAM (4 Nos)
HDD : 1.2 TB (3 Nos)
Hot Air Oven
Double Wall Chamber
Maximum temperature 210˚C.
Continues operation 200˚C.
Accuracy ±1˚C
Material : Cold rolled Mild Steel with mirror powder coating.
Fan for uniform heating.
Digital on / off controller Accuracy of ±1˚C
Pellet Making Setup
Lenovo
Capacity : 5 Ton
Loading type : Hydraulic
Travel of Ram : 15 cm
Pressure gauge : External
Cast iron : 30mm die set
Embedded Boards
Machine Learning Kit - Arduino Tiny
Nano 33 BLE Sense Board
image/ video capture sensor
Tiny Machine Learning Shield
USB A to Micro USB Cable
AI board for Embedded Artificial Intelligence -- Beagle Bone
TI AM5729 Dual-Core ARMCortex-A15 processor running at 1.5GHz
Memory: 1GB RAM and 16GB on-board eMMC Flash
Connectivity: Gigabit Ethernet, 2.4/5GHz WiFi, and Bluetooth
Micro Python pyboard with headers
STM32F405RG microcontroller
168 MHz Cortex M4 CPU with hardware floating point
192KiB RAM
24 GPIO plus LED and switch GPIO available on bottom row
DEVELOPER KIT -- JETSON XAVIER NX
GPU: 384-core NVIDIA Volta™ GPU with 48 Tensor Cores
CPU: 6-core NVIDIA Carmel ARM®v8.2 64-bit CPU 6 MB L2+4 MB L3
Memory: 8 GB 128-bit LPDDR4x 59.7GB/s
Development board - Galileo board
86-bit Intel GALILEO GEN 2 development board
Intel X1000 chip quark system
Interface Type: Ethernet, I2C, SPI, UART, USB
Operating Supply Voltage: 7 V to 15 V
Processor board -- Raspberry Pi Zero
1GHz single-core CPU
512MB RAM
Mini HDMI port
Micro USB OTG port
Micro USB power
Mega board -- Arduino
Microcontroller: ATmega2560
Operating Voltage: 5V
Input Voltage: 7-12V
Input Voltage: 7-12V
Clock Speed: 16 MHz
WIFI and Bluetooth -- ESP32 Development Board
With support LWIP Protocol and Free RTOS
Supporting three modes: Access point, Station mode, and Access point + Station mode
Includes CP2102 USB-UART bridge
Wave share 10.1 Inch Capacitive HDMI LCD
Display (B) with Case 1280x800
IPS screen,1280 x 800 hardware resolution
Toughened glass capacitive touch panel, 6H hardness
HDMI interface for displaying, USB interface for touch control
Supports 5-level backlight adjustment
Processor board -- Raspberry pi 4b (8GB RAM)
Quad-Core 64-bit Broadcom 2711, Cortex A72 Processor
WLAN 802.11 b/g/n/ac (2.4 + 5.0 GHz)
LAN RJ45 10/100/1000 Mbit (Gigabit LAN over USB 3.0)
Operating Power 5V (or) 3A via USB Type-C port
AURIX TC399-KIT - Infineon’s
TC399 AURIX™ TC3xx Controller in LFBGA-516 Package
Crystal 20MHz (default) or External Clock
Asynchronous SRAM upto 2MB
Synchronous SRAM upto 4MB
